3528 RGBI LED
3528 RGBI LED
数量
| 型号 (WEJ P/N) | 发光颜色 (Emitted Color) | 发光角度 (Viewing Angle) | 正向电流 (Forward Current) | 正向电压 (Forward voltage) | 波段 (Dominant wavelength) | 发光强度 (Luminous intensity) |
| WEJT28GD-RGBJP-6D9BEKP02 | 红光 (Red) | 120° | 20mA | 1.8-2.6V @20mA | 620-630nm | 200-270mcd @20mA |
| 绿光 (Green) | 20mA | 2.8-3.6V @20mA | 515-530nm | 1000-1300mcd @20mA | ||
| 蓝光 (Blue) | 20mA | 2.8-3.6V @20mA | 465-475nm | 180-230mcd @20mA | ||
| 红外 (IR) | 30mA | 1.2-1.6V @20mA | 840-860nm | 1.5-3.0m/sr @20mA |
