2727 RGB LED
Black Face SMD
•Precise Narrow‑bin Sorting, High Color Consistency
•Gold wire bonding for superior long-term stability
•High brightness with ultra-low power consumption
•Large-size LED chip with PV protective coating
•Precise RGB primary color binning & matching
•Enables glasses-free 3D display with wide viewing angle
•Gold wire bonding for superior long-term stability
•High brightness with ultra-low power consumption
•Large-size LED chip with PV protective coating
•Precise RGB primary color binning & matching
•Enables glasses-free 3D display with wide viewing angle
Quantity
SMD 2727 RGB LED for Outdoor Display Screen
High‑precision narrow‑bin sorting for 2727 RGB LEDs. RGB wavelength strictly controlled within ±2nm, brightness & forward voltage matched in same bin. Eliminates color difference, uneven brightness and color patches fundamentally, ensuring long‑term screen consistency for display screens.
Get Free Samples Click Here
| Product | Model No. | Color | Brightness （mcd） | Wavelength （nm） | Volt (V) | Current (mA) | Spec. Download | ||||
| Min. | Typ. | Max. | Min. | Max. | Min. | Max. | |||||
| 2727 RGB LED | WEJT27FRGB0-AGBBEKP01 | Red | 310 | 470 | 1150 | 615 | 630 | 1.8 | 2.5 | 15 | ⬇ |
| Green | 500 | 750 | 2220 | 515 | 535 | 2.5 | 3.4 | 8 | |||
| Blue | 70 | 120 | 370 | 465 | 480 | 2.5 | 3.4 | 5 | |||
